The liquid filled measuring system changes its volume as a function of
temperature changes. A two-way contact therefore is actuated by mechanical
transmission.
The temperature controller is interrupted when the measuring
system leaks. When the minimum sensor temperature is underflowed the contact
opens also, but will reset itself when temperature rise. Zones 1 & 2, 21
& 22
|
Measuring range |
- 20 °C ... + 50 °C |
0 °C ... + 120 °C |
+ 50 °C ... + 300 °C |
|
|
Rated Voltage |
max. 250 V, AC |
max. 250 V, AC |
max. 250 V, AC |
|
|
Rated current |
5 A |
5 A |
5 A |
|
|
Sensor |
||||
|
Diameter |
6 mm | 6 mm | 6 mm | |
|
Length |
129 mm | 81 mm | 51 mm | |
|
Contact |
1 changeover | 1 changeover | 1 changeover | |
|
Setpoint accuracy |
0 K ... + 3,5 K |
0 K ... + 6 K |
0 K ... + 12,5 K |
|
|
Allowable temperature limits at the sensor |
||||
|
Minimum |
- 30 °C |
- 10 °C |
- 15 °C |
|
|
Maximum |
+ 60 °C |
+ 140 °C |
+ 345 °C |
|
|
Ambient temperature |
- 20 °C ... +50 °C | - 20 °C ... +50 °C | - 15 °C ... +50 °C | |
|
Terminal |
4 x cage clamp terminal 2,5 mm2 |
4 x cage clamp terminal 2,5 mm2 |
4 x cage clamp terminal 2,5 mm2 |
|
| 防爆温度表的规格参数 | |
|---|---|
| 类型 | - |
| 适用场所 | IIA,IIB,IIC | 其他参数 |
| 产品型号 | 8040/1260-R5A |
| 防爆标志 | - |
| 供货周期 | 5-10天 |
| 防爆合格证编号 | - |
| 尺寸图 | - |
|
