概述
YB400~YB710系列高压隔爆型三相异步电动机的功率等级、安装尺寸符合我国标准,功率范围从160KW~1400KW。电动机符合中国标准GB3836.1-2000《爆炸性气体环境用电气设备 第1部分:通用要求》和GB3836.2-2000《爆炸性气体环境用电气设备第2部分:隔爆型“d”》的规定,制成隔爆型dI、dIIAT4、dIIBT4,适用于具有爆炸性气体混合物的场所。
I 类:dI,适用于具有甲烷或煤矿爆炸危险性混合物存在的场所及煤矿井下非采掘工作面用电气设备;
II类:适用于工厂用电气设备。
dIIAT4,工厂具有IIA级,T1、T2、T3、T4组爆炸性气体混合物存在的场所;
dIIBT4,工厂具有IIA、IIB级,T1、T2、T3、T4组爆炸性气体混合物存在的场所;
本系列电机主体外壳防护等级按IP54设计,可制成IP55;接线盒为IP54,可制成IP55;
电动机的功率、转速及机座号的对应关系见表1(6000V)、表2(10000V),技术数据见表3(6000V)、表4(10000V);
结构说明
电动机冷却方式为IC411,即带有内循环通风自扇冷式。
电动机绝缘等级为F级,定子线圈采用薄膜绕包扁铜线绕制,云母带半迭包,定子绕组经VPI真空压力浸漆后具有较高的电气强度、机械强度、防潮性能和热稳定性能。
电动机转子采用笼型结构。
电动机接线盒为半斜面式,盒内有宽敞的接线腔,接线端子绝缘采用优质DMC塑料。
电动机设置有定子测温,轴承测温和防冷凝加热装置等。
电动机采用滚动轴承结构,并设有注油装置,可不停机补充润滑脂。
使用条件
额定电压:6000V、10000V
额定频率:50Hz
工作制:S1
环境空气温度:-20℃~+40℃
海拔高度:不超过1000m
表1 Table 1(6000V)
机座号 Frame size |
同步转速Synchronous Speed(r/min) |
|||
1500 |
1000 |
750 |
600 |
|
功率Output(kW) |
||||
YB400S1 |
200 |
160 |
— |
— |
YB400S2 |
220 |
185 |
— |
— |
YB400M1 |
250 |
200 |
160 |
— |
YB400M2 |
280 |
220 |
185 |
— |
YB400M3 |
315 |
250 |
200 |
— |
YB450S1 |
315 |
250 |
200 |
160 |
YB450S2 |
355 |
280 |
220 |
185 |
YB450S3 |
400 |
315 |
250 |
200 |
YB450M1 |
450 |
355 |
280 |
220 |
YB450M2 |
500 |
400 |
315 |
250 |
YB560S1 |
500 |
400 |
315 |
— |
YB560S2 |
560 |
450 |
355 |
— |
YB560M1 |
630 |
500 |
400 |
— |
YB560M2 |
710 |
560 |
450 |
— |
YB630S1 |
800 |
630 |
500 |
— |
YB630S2 |
900 |
710 |
560 |
— |
YB630M1 |
1000 |
800 |
630 |
— |
YB630M2 |
1120 |
900 |
710 |
— |
表2 Table2(10000V)
机座号 Frame size |
同步转速Synchronous Speed(r/min) |
|||
1500 |
1000 |
750 |
600 |
|
功率Output(kW) |
||||
YB710S1 |
900 |
710 |
560 |
— |
YB710S2 |
1000 |
800 |
630 |
— |
YB710M1 |
1120 |
900 |
710 |
— |
YB710M2 |
1250 |
1000 |
800 |
— |
YB710M3 |
1400 |
1120 |
900 |
— |
表3Table3(6000V)
型号 Type |
功率 Rated Output (Kw) |
电流 RatedCurrent (A) |
转速 Ratedoutput (r/min) |
效率 Eff (%) |
功率因数 Power factor (cosφ) |
堵转转矩 额定转矩 Locked torqueRated torque |
堵转电流 额定电流 Locked currentRated current |
转矩 额定转距 Max torque Rated torque |
振动 Vibration(mm/s) |
噪音 Noise dB(A) |
飞轮力矩 Moment of inertia (kg.m2) |
重量 Weight (kg) |
同步转速1500转/分 Synchronous speed 1500r/min ` `` |
||||||||||||
YB400S1-4 |
200 |
24.2 |
1488 |
93.5 |
0.85 |
1.2 |
6.5 |
2.2 |
2.8 |
106 |
32 |
2050 |
YB400S2-4 |
220 |
26.5 |
35 |
2100 |
||||||||
YB400M1-4 |
250 |
30.3 |
108 |
40 |
2240 |
|||||||
YB400M2-4 |
280 |
33.9 |
44 |
2320 |
||||||||
YB400M3-4 |
315 |
38.1 |
47 |
2440 |
||||||||
YB450S1-4 |
315 |
37.9 |
94 |
60 |
3100 |
|||||||
YB450S2-4 |
355 |
42.8 |
65 |
3200 |
||||||||
YB450S3-4 |
400 |
48.2 |
75 |
3350 |
||||||||
YB450M1-4 |
450 |
54.2 |
85 |
3600 |
||||||||
YB450M2-4 |
500 |
60.2 |
100 |
3750 |
||||||||
YB560S1-4 |
500 |
58.9 |
1490 |
95.0 |
0.86 |
0.90 |
6.0 |
2.2 |
2.8 |
108 |
72 |
4800 |
YB560S2-4 |
560 |
66 |
111 |
82 |
5000 |
|||||||
YB560M1-4 |
630 |
73.8 |
95.5 |
90 |
5200 |
|||||||
YB560M2-4 |
710 |
83.2 |
96 |
5300 |
||||||||
YB630S1-4 |
800 |
93.7 |
0.86 |
6.5 |
130 |
6370 |
||||||
YB630S2-4 |
900 |
105.4 |
138 |
6520 |
||||||||
YB630M1-4 |
1000 |
116.6 |
96.0 |
150 |
6850 |
|||||||
YB630M2-4 |
1120 |
130.5 |
113 |
158 |
7005 |
|||||||
同步转速1000转/分 Synchronous speed 1000r/min |
||||||||||||
YB400S1-6 |
160 |
21.2 |
987 |
93 |
0.82 |
1.2 |
6.0 |
2.0 |
2.8 |
102 |
47 |
2100 |
YB400S2-6 |
185 |
23.3 |
50 |
2230 |
||||||||
YB400M1-6 |
200 |
25.2 |
54 |
2310 |
||||||||
YB400M2-6 |
220 |
27.8 |
60 |
2400 |
||||||||
YB400M3-6 |
250 |
31.2 |
65 |
2500 |
||||||||
YB450S1-6 |
250 |
31.2 |
0.83 |
105 |
75 |
3200 |
||||||
YB450S2-6 |
280 |
34.9 |
85 |
3300 |
||||||||
YB450S3-6 |
315 |
39.3 |
95 |
3450 |
||||||||
YB450M1-6 |
355 |
44.3 |
110 |
3700 |
||||||||
YB450M2-6 |
400 |
49.9 |
125 |
3850 |
||||||||
型号 Type |
功率 Rated Output (Kw) |
电流 RatedCurrent (A) |
转速 Ratedoutput (r/min) |
效率 Eff (%) |
功率因数 Power factor (cosφ) |
堵转转矩 额定转矩 Locked torqueRated torque |
堵转电流 额定电流 Locked currentRated current |
转矩 额定转距 Max torque Rated torque |
振动 Vibration(mm/s) |
噪音 Noise dB(A) |
飞轮力矩 Moment of inertia (kg.m2) |
重量 Weight (kg) |
同步转速1000转/分 Synchronous speed 1000r/min ` `` |
||||||||||||
YB560S1-6 |
400 |
47.8 |
987 |
94.5 |
0.85 |
0.9 |
5.5 |
2.2 |
2.8 |
105 |
98 |
4750 |
YB560S2-6 |
450 |
53.6 |
95.0 |
108 |
4900 |
|||||||
YB560M1-6 |
500 |
59.6 |
114 |
5150 |
||||||||
YB560M2-6 |
560 |
66.6 |
123 |
5300 |
||||||||
YB630S1-6 |
630 |
76.0 |
990 |
0.84 |
108 |
215 |
6330 |
|||||
YB630S2-6 |
710 |
85.6 |
226 |
6450 |
||||||||
YB630M1-6 |
800 |
96.0 |
95.5 |
243 |
6790 |
|||||||
YB630M2-6 |
900 |
108.0 |
254 |
6900 |
||||||||
同步转速750转/分 Synchronous speed 750r/min |
||||||||||||
YB400M1-8 |
160 |
20.7 |
742 |
93.0 |
0.80 |
1.1 |
6.0 |
2.0 |
2.8 |
99 |
56 |
2260 |
YB400M2-8 |
185 |
23.9 |
60 |
2440 |
||||||||
YB400M3-8 |
200 |
25.9 |
65 |
2050 |
||||||||
YB450S1-8 |
200 |
25.9 |
80 |
3050 |
||||||||
YB450S2-8 |
220 |
28.5 |
90 |
3180 |
||||||||
YB450S3-8 |
250 |
32.3 |
102 |
100 |
3330 |
|||||||
YB450M1-8 |
280 |
36.2 |
115 |
3550 |
||||||||
YB450M2-8 |
315 |
40.7 |
130 |
3700 |
||||||||
YB560S1-8 |
315 |
38.9 |
94.0 |
0.83 |
0.9 |
|
|
|
102 |
128 |
5100 |
|
YB560S2-8 |
355 |
4.07 |
|
|
|
102 |
141 |
5300 |
||||
YB560M1-8 |
400 |
49.1 |
94.5 |
5.5 |
2.0 |
2.8 |
102 |
148 |
5600 |
|||
YB560M2-8 |
450 |
55.1 |
102 |
160 |
5750 |
|||||||
YB630S1-8 |
500 |
61.8 |
743 |
95.0 |
102 |
216 |
6465 |
|||||
YB630S2-8 |
560 |
68.3 |
0.83 |
105 |
230 |
6675 |
||||||
YB630M1-8 |
630 |
76.9 |
245 |
7010 |
||||||||
YB630M2-8 |
710 |
86.2 |
95.5 |
258 |
7135 |
|||||||
同步转速600转/分 Synchronous speed 600r/min |
||||||||||||
YB450S1-10 |
160 |
21.4 |
592 |
90 |
0.80 |
1.0 |
5.5 |
2.0 |
2.8 |
99 |
80 |
3050 |
YB450S2-10 |
185 |
24.7 |
90 |
3200 |
||||||||
YB450S3-10 |
200 |
26.7 |
100 |
3350 |
||||||||
YB450M1-10 |
220 |
29.4 |
115 |
3600 |
||||||||
YB450M2-10 |
250 |
33.4 |
102 |
130 |
3750 |
表4 Table4(10000V)
型号 Type |
功率 Rated Output (Kw) |
电流 RatedCurrent (A) |
转速 Ratedoutput (r/min) |
效率 Eff (%) |
功率因数 Power factor (cosφ) |
堵转转矩 额定转矩 Locked torqueRated torque |
堵转电流 额定电流 Locked currentRated current |
转矩 额定转距 Max torque Rated torque |
振动 Vibration(mm/s) |
噪音 Noise dB(A) |
重量 Weight (kg) |
YB710S1-4 |
900 |
63.6 |
1490 |
95.5 |
0.86 |
1.0 |
6.0 |
2.0 |
2.8 |
111 |
9000 |
YB710S2-4 |
1000 |
69.9 |
96 |
9230 |
|||||||
YB710M1-4 |
1120 |
78.3 |
113 |
9750 |
|||||||
YB710M2-4 |
1250 |
85.4 |
0.88 |
10050 |
|||||||
YB710M3-4 |
1400 |
95.7 |
10100 |
||||||||
YB710S1-6 |
710 |
50 |
990 |
94.6 |
0.84 |
0.8 |
6.0 |
2.0 |
2.8 |
108 |
8700 |
YB710S2-6 |
800 |
57.5 |
95.5 |
8900 |
|||||||
YB710M1-6 |
900 |
64.8 |
9600 |
||||||||
YB710M2-6 |
1000 |
70.8 |
96 |
0.85 |
9800 |
||||||
YB710M3-6 |
1120 |
79.2 |
110 |
10100 |
|||||||
YB710S1-8 |
560 |
41.4 |
743 |
94 |
0.80 |
0.8 |
6.0 |
2.0 |
2.8 |
105 |
8900 |
YB710S2-8 |
630 |
46 |
95 |
9200 |
|||||||
YB710M1-8 |
710 |
52 |
95.5 |
9600 |
|||||||
YB710M2-8 |
800 |
58.3 |
9800 |
||||||||
YB710M3-8 |
900 |
66 |
10000 |
YB2、YBK2系列低压隔爆型三相异步电动机
● 概述
YB2、YBK2系列低压隔爆型三相异步电动机的功率等级、安装尺寸符合我国标准。电动机符合中国标准GB3836.1-2000《爆炸性气体环境用电气设备 第1部分:通用要求》和GB3836.2-2000《爆炸性气体环境用电气设备第2部分:隔爆型“d”》的规定,制成隔爆型dI,适用于具有爆炸性气体混合物的场所。
本系列电机主体外壳防护等级按IP54设计,可制成IP55;接线盒为IP54,可制成IP55;
电动机的功率、转速及机座号的对应关系:YB2系列电机见表5,YBK2系列电机见表6。技术数据YB2系列电机见表7, YBK2系列电机见表8;
表5 Table5(660/1140V)
机座号 Frame size |
同步转速Synchronous Speed(r/min) |
||
1500 |
1000 |
750 |
|
功率Output(kW) |
|||
YB2-400M3 |
315 |
- |
- |
YB2-400M4 |
355 |
- |
- |
YB2-400M5 |
400 |
- |
- |
YB2-400M6 |
500 |
- |
- |
YB2-450S2 |
355 |
- |
- |
YB2-450S3 |
400 |
- |
- |
YB2-450M1 |
450 |
- |
- |
YB2-450M2 |
500 |
- |
- |
YB2-450M3 |
- |
- |
355 |
表6-1Table6-1(380/660V)
机座号 Frame size |
同步转速Synchronous Speed(r/min) |
|||
3000 |
1500 |
1000 |
750 |
|
功率Output(kW) |
||||
YBK2-225S |
- |
37 |
- |
18.5 |
YBK2-225M |
45 |
45 |
30 |
22 |
YBK2-315S |
110 |
110 |
75 |
55 |
YBK2-315M |
132 |
132 |
90 |
75 |
YBK2-315L1 |
160 |
160 |
110 |
90 |
YBK2-315L2 |
200 |
200 |
132 |
110 |
YBK2-355S1 |
185 |
185 |
- |
- |
YBK2-355S2 |
200 |
200 |
- |
- |
YBK2-355S |
- |
- |
160 |
- |
YBK2-355M1 |
220 |
220 |
185 |
- |
YBK2-355M2 |
250 |
250 |
200 |
- |
YBK2-355M |
- |
- |
- |
160 |
YBK2-355L1 |
280 |
280 |
220 |
185 |
YBK2-355L2 |
315 |
315 |
250 |
200 |
表6-2Table6-2(660/1140V)
机座号 Frame size |
同步转速Synchronous Speed(r/min) |
|||
3000 |
1500 |
1000 |
750 |
|
功率Output(kW) |
||||
YBK2-225S |
- |
37 |
- |
- |
YBK2-225M |
45 |
45 |
- |
- |
YBK2-315S |
110 |
110 |
75 |
- |
YBK2-315M |
132 |
132 |
90 |
- |
YBK2-315L1 |
160 |
160 |
110 |
- |
YBK2-315L2 |
200 |
200 |
132 |
- |
YBK2-355S1 |
185 |
185 |
- |
- |
YBK2-355S2 |
200 |
200 |
- |
- |
YBK2-355S |
- |
- |
160 |
- |
YBK2-355M1 |
220 |
220 |
185 |
- |
YBK2-355M2 |
250 |
250 |
200 |
- |
YBK2-355M |
- |
- |
- |
- |
YBK2-355L1 |
280 |
280 |
220 |
- |
YBK2-355L2 |
315 |
315 |
250 |
- |
表7Table7(660/1140V)
型号 Type |
功率 Rated Output (Kw) |
电流 RatedCurrent (A) |
转速 Ratedoutput (r/min) |
效率 Eff (%) |
功率因数 Power factor (cosφ) |
堵转转矩 额定转矩 Locked torqueRated torque |
堵转电流 额定电流 Locked currentRated current |
转矩 额定转距 Max torque Rated torque |
振动 Vibration(mm/s) |
噪音 Noise dB(A) |
重量 Weight (kg) |
YB2-400M3-4 |
315 |
332/192 |
1487 |
93.5 |
0.85 |
2.1 |
6.5 |
2.2 |
2.8 |
108 |
2490 |
YB2-400M4-4 |
355 |
372/215 |
1.2 |
2608 |
|||||||
YB2-400M5-4 |
400 |
419/242 |
2727 |
||||||||
YB2-400M6-4 |
500 |
520/300 |
3161 |
||||||||
YB2-450S2-4 |
355 |
362/209 |
1486 |
94 |
3073 |
||||||
YB2-450S3-4 |
400 |
405/234 |
3191 |
||||||||
YB2-450M1-4 |
450 |
456/263 |
3401 |
||||||||
YB2-450M2-4 |
500 |
509/294 |
3562 |
||||||||
YB2-450M3-8 |
355 |
409.8/236.6 |
745 |
0.8 |
0.9 |
2.0 |
102 |
3690 |
表8-1Table8-1(380/660V)
型号 Type |
功率 Rated Output (Kw) |
电流 RatedCurrent (A) |
转速 Ratedoutput (r/min) |
效率 Eff (%) |
功率因数 Power factor (cosφ) |
堵转转矩 额定转矩 Locked torqueRated torque |
堵转电流 额定电流 Locked currentRated current |
转矩 额定转距 Max torque Rated torque |
振动 Vibration(mm/s) |
噪音 Noise dB(A) |
重量 Weight (kg) |
|||
同步转速3000转/分 Synchronous speed 3000r/min |
||||||||||||||
YBK2-225M-2 |
45 |
79/45.6 |
2960 |
92.5 |
0.90 |
2.0 |
7.5 |
2.3 |
3.5 |
94 |
|
|||
YBK2-315S-2 |
110 |
192.2/111 |
2975 |
94.0 |
0.91 |
1.8 |
7.0 |
98 |
|
|||||
YBK2-315M-2 |
132 |
228.6/132 |
94.5 |
|
||||||||||
YBK2-315L1-2 |
160 |
276.2/159.5 |
94.6 |
0.92 |
101 |
|
||||||||
YBK2-315L2-2 |
200 |
343.5/198.3 |
94.8 |
|
||||||||||
YBK2-355S1-2 |
185 |
320/184.7 |
94.6 |
0.91 |
1.8 |
2.2 |
|
|||||||
YBK2-355S2-2 |
200 |
345.2/199.3 |
2978 |
94.8 |
0.92 |
1.8 |
|
|||||||
YBK2-355M1-2 |
220 |
376.5/217.4 |
2980 |
94.8 |
1.6 |
105 |
|
|||||||
YBK2-355M2-2 |
250 |
426/246 |
2976 |
95.2 |
|
|||||||||
YBK2-355L1-2 |
280 |
474.8/274.1 |
2980 |
95.2 |
|
|||||||||
YBK2-355L2-2 |
315 |
533.3/307.9 |
2977 |
95.4 |
|
|||||||||
同步转速1500转/分 Synchronous speed 1500r/min |
||||||||||||||
YBK2-225S-4 |
37 |
69.5/40.1 |
1478 |
92.5 |
0.87 |
2.2 |
7.2 |
2.4 |
3.5 |
85 |
|
|||
YBK2-225M-4 |
45 |
83.3/48.1 |
1476 |
92.8 |
84 |
|
||||||||
YBK2-315S-4 |
110 |
195.9/113.1 |
1487 |
94.5 |
0.89 |
2.1 |
7.0 |
96 |
|
|||||
YBK2-315M-4 |
132 |
234.5/135.4 |
94.8 |
|
||||||||||
YBK2-315L1-4 |
160 |
282.6/163.2 |
95.0 |
0.90 |
100 |
|
||||||||
YBK2-315L2-4 |
200 |
351.5/203 |
95.2 |
2.3 |
|
|||||||||
YBK2-355S1-4 |
185 |
325.6/188 |
94.9 |
0.89 |
2.1 |
2.2 |
|
|||||||
YBK2-355S2-4 |
200 |
350.7/202.5 |
94.9 |
0.89 |
2.1 |
|
||||||||
YBK2-355M1-4 |
220 |
384.7/222.1 |
94.9 |
0.90 |
104 |
|
||||||||
YBK2-355M2-4 |
250 |
435.1/251.2 |
95.2 |
|
||||||||||
YBK2-355L1-4 |
280 |
486.4/280.8 |
|
|||||||||||
YBK2-355L2-4 |
315 |
546/315.24 |
|
|||||||||||
同步转速1000转/分 Synchronous speed 1000r/min |
||||||||||||||
YBK2-225M-6 |
30 |
57.9/33.4 |
983 |
92.0 |
0.86 |
2.1 |
7.0 |
2.4 |
3.5 |
82 |
|
|||
YBK2-315S-6 |
75 |
139.3/80.4 |
988 |
93.5 |
2.0 |
2.2 |
90 |
|
||||||
YBK2-315M-6 |
90 |
166/95.8 |
988 |
93.8 |
|
|||||||||
YBK2-315L1-6 |
110 |
201.2/116 |
988 |
94.0 |
|
|||||||||
YBK2-315L2-6 |
132 |
240.8/139 |
988 |
94.2 |
0.87 |
|
||||||||
YBK2-355S-6 |
160 |
286/165.1 |
990 |
94.5 |
0.88 |
1.9 |
2.0 |
96 |
|
|||||
YBK2-355M1-6 |
185 |
330/190.5 |
990 |
|
||||||||||
YBK2-355M2-6 |
200 |
355.9/205.5 |
990 |
|
||||||||||
YBK2-355L1-6 |
220 |
391.8/262.2 |
990 |
|
||||||||||
YBK2-355L2-6 |
250 |
442.7/255.6 |
990 |
|
||||||||||
同步转速750转/分 Synchronous speed 750r/min |
||||||||||||||
YBK2-225S-8 |
18.5 |
39.8/23 |
733 |
90.0 |
0.78 |
2.0 |
6.5 |
2.2 |
3.5 |
80 |
|
|||
YBK2-225M-8 |
22 |
46.6/26.9 |
732 |
90.5 |
|
|||||||||
YBK2-315S-8 |
55 |
109.7/63.4 |
740 |
92.8 |
0.81 |
1.9 |
88 |
|
||||||
YBK2-315M-8 |
75 |
147.5/85.2 |
740 |
93.0 |
|
|||||||||
YBK2-315L1-8 |
90 |
176.8/102 |
740 |
93.8 |
0.82 |
|
||||||||
YBK2-315L2-8 |
110 |
215/124 |
740 |
94.0 |
|
|||||||||
YBK2-355S-8 |
132 |
253.7/146.5 |
742 |
94.2 |
0.82 |
1.8 |
6.5 |
2.0 |
3.5 |
95 |
|
|||
YBK2-355M-8 |
160 |
305.2/176.2 |
742 |
|
||||||||||
YBK2-355L1-8 |
185 |
352.6/203.6 |
742 |
93 |
|
|||||||||
YBK2-355L2-8 |
200 |
379.8/219.3 |
742 |
94.5 |
0.83 |
|
||||||||
表8-2Table8-2(660/1140V)
型号 Type |
功率 Rated Output (Kw) |
电流 RatedCurrent (A) |
转速 Ratedoutput (r/min) |
效率 Eff (%) |
功率因数 Power factor (cosφ) |
堵转转矩 额定转矩 Locked torqueRated torque |
堵转电流 额定电流 Locked currentRated current |
转矩 额定转距 Max torque Rated torque |
振动 Vibration(mm/s) |
噪音 Noise dB(A) |
重量 Weight (kg) |
|
同步转速3000转/分 Synchronous speed 3000r/min |
||||||||||||
YBK2-225M-2 |
45 |
46.4/26.8 |
2960 |
92.5 |
0.90 |
2.0 |
7.5 |
2.3 |
3.5 |
94 |
|
|
YBK2-315S-2 |
110 |
111/64 |
2974 |
94.0 |
0.91 |
1.8 |
7.0 |
98 |
|
|||
YBK2-315M-2 |
132 |
132.3/76.4 |
2974 |
94.5 |
|
|||||||
YBK2-315L1-2 |
160 |
159/91.8 |
2974 |
94.6 |
0.92 |
101 |
|
|||||
YBK2-315L2-2 |
200 |
197.8/114.2 |
2974 |
94.8 |
|
|||||||
YBK2-355S1-2 |
185 |
184.1/106.3 |
2975 |
94.6 |
0.91 |
2.2 |
|
|||||
YBK2-355S2-2 |
200 |
199.2/115/ |
2979 |
94.8 |
0.92 |
|
||||||
YBK2-355M1-2 |
220 |
217.5/125.6 |
2980 |
94.8 |
1.6 |
105 |
|
|||||
YBK2-355M2-2 |
250 |
245.4/141.7 |
2978 |
95.2 |
|
|||||||
YBK2-355L1-2 |
280 |
273.3/157.8 |
2978 |
95.2 |
|
|||||||
YBK2-355L2-2 |
315 |
307.4/177.5 |
2975 |
95.4 |
0.95 |
|
||||||
同步转速1500转/分 Synchronous speed 1500r/min |
||||||||||||
YBK2-225S-4 |
37 |
40/23.3 |
1478 |
92.5 |
0.87 |
2.2 |
7.2 |
2.4 |
3.5 |
85 |
|
|
YBK2-225M-4 |
45 |
48/27.7 |
1476 |
92.8 |
84 |
|
||||||
YBK2-315S-4 |
110 |
112.6/65 |
1487 |
94.5 |
0.89 |
2.1 |
7.0 |
96 |
|
|||
YBK2-315M-4 |
132 |
134.4/77.6 |
1487 |
94.8 |
|
|||||||
YBK2-315L1-4 |
160 |
162.5/93.8 |
1487 |
95.0 |
0.90 |
100 |
|
|||||
YBK2-315L2-4 |
200 |
202.5/116.9 |
1487 |
95.2 |
2.3 |
|
||||||
YBK2-355S1-4 |
185 |
187.8/108.4 |
1488 |
94.9 |
0.89 |
2.2 |
|
|||||
YBK2-355S2-4 |
200 |
201.6/116.4 |
1487 |
|
||||||||
YBK2-355M1-4 |
220 |
221.4/127.8 |
1487 |
0.90 |
104 |
|
||||||
YBK2-355M2-4 |
250 |
250.6/144.7 |
1487 |
95.2 |
|
|||||||
YBK2-355L1-4 |
280 |
280/161.7 |
1487 |
|
||||||||
YBK2-355L2-4 |
315 |
314.4/181.5 |
1488 |
|
||||||||
同步转速1000转/分 Synchronous speed 1000r/min |
||||||||||||
YBK2-315S-6 |
75 |
80/46.2 |
988 |
93.5 |
|
2.0 |
|
2.2 |
|
90 |
|
|
YBK2-315M-6 |
90 |
96/55.4 |
93.8 |
|
||||||||
YBK2-315L1-6 |
110 |
116.1/67 |
94.0 |
|
||||||||
YBK2-315L2-6 |
132 |
138.5/80 |
990 |
94.2 |
0.87 |
|
||||||
YBK2-355S-6 |
160 |
165.6/95.6 |
94.5 |
0.88 |
1.9 |
2.0 |
96 |
|
||||
YBK2-355M1-6 |
185 |
190.4/109.9 |
|
|||||||||
YBK2-355M2-6 |
200 |
205.6/118.7 |
|
|||||||||
YBK2-355L1-6 |
220 |
225/129.9 |
|
|||||||||
YBK2-355L2-6 |
250 |
254.8/147.1 |
|
|||||||||
一、订货须知
正常订货
1、本样本提供数据仅供用户参考,具体如有变动,恕不另行通知;
2、按本目录中提供的外形及数据表订购的产品须写明以下内容:产品型号、功率、电压等级、频率、安装方式、防护等级、热保护元件类型;
3、特殊要求:
▲海拔,本目录产品适用于海拔1000m以下,否则应予以说明;
▲环境温度,高于40℃时应注明;
▲电压等级,非标电压时应注明;
非正常订货
若技术指标、功率、绕组(或端盖)热保护装置、接口尺寸等与数据表不一致时,则属非正常订货,应由供需双方签订技术协议。协议除包括上述内容外,还应注明电动机所拖动的设备,以及重新商定的技术指标及外形安装尺寸。对于输送机用3.3KV电机,电缆的引出设计为压盘式和高压电缆连接器(3.3KV高压电缆连接器)两种方式,订货时合同中如无要求,发货时按压盘出厂;
二、日常维护中注意事项
1、电动机到货后如不能立即安装,应储存于干燥处,并应避免振动及冲击伤害,电动机使用前须进行如下电气检验:
定子绕组对机壳及绕组相互间的冷态绝缘电阻不低于下表的规定
电压(V) |
380 |
660 |
1140 |
3300 |
6000 |
10000 |
电阻(Ω) |
20 |
25 |
30 |
100 |
100 |
100 |
2、经常清理电动表面污垢,否则,影响电机散热,也容易引起表面腐蚀;
3、经常清除接线盒中冷凝水及滋生的霉菌:进线口处的密封状况要完好如初;
4、注意有无局部过热及不正常的的响声,特别是轴承部位;
5、按要求加注润滑脂;
6、安装在金属焊接构架上的电机,应注意构架在使用中是否变形;
7、电动机长期不用时,应将水道内的积水排出,防止结冰胀裂水室。特别注意水口不用时应将螺堵拧上,防止杂店物进入水道影响水道畅通;
三、拆装注意事项
1、电动机的下列零件的加工与配合均有隔爆要求,在使用维护中应予以特别注意:
(1)机座; (2)前端盖; (3)后端盖; (4)前内盖; (5)后内盖;
(6)绝缘子; (7)端子板; (8)接线柱; (9)轴(转子); (10)接线盒盖;
(11)接线盒座; (12)电缆引入装置。
2、拆装时不要磕碰电机绕组,若电机有内风扇,且其外径大于定子内径,抽出转子时应注意方向。
上述零件的隔爆面每次装配前应涂204-1无酸防锈油;
高压隔爆型三相异步电动机规格参数 | |
---|---|
适用场所 | IIA,IIB |
安装方式 | B3,其它 |
电压 | 6000V,10000V,其它 |
功率 | 160KW~1400KW |
极数 | 2~8 |
绝缘等级 | F |
防护等级 | IP54 |
频率 | 50Hz |
机座号 | YB400~YB710 |
冷却方式 | IC411 |
工作制 | S1 |
海拔 | 不超过1000m |
环境温度 | -20℃~+40℃ | 其他参数 |
产品型号 | YB |
防爆标志 | - |
供货周期 | 15天 |
防爆合格证编号 | - |
尺寸图 |
违法和不良信息举报投诉电话:0377-62377728 举报邮箱:fbypt@ex12580.com
